Quick Specifications
Quick Specifications
- Type : HOODS
- Style : PROFESSIONAL HOOD
- Height : 32.5"
- Depth : 28"
- Energy Star Rated : NO
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
- Airflow Control Technology™ (ACT™)
- Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- ICON Touch® Controls
- ICON Touch Controls seamlessly integrate into the hoods stainless steel canopy, which lets users control functions such as the 5 speeds, delay-off, dual-level lighting, and auto reminders. With its blue LED indicator lights and sleek modern aesthetic, the ICON Touch Controls are the future of ventilation control technology.
- LumiLight LED Lighting
- LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
- Dual-Level Lighting
- The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Quick-Lock Installation System
- Zephyrs Quick-Lock Installation System is an innovative, hassle-free method for installing island range hoods. A quick-lock motion lets the user assemble the frame, lift the hood and lock it into place on the frame and then assemble the 4-piece duct covers. This easy three-step process ensures the island hood is securely installed without additional build-out required. While most island range hood installations require at least three people, Zephyrs Quick-Lock Installation can be completed by one or two people.
- Hybrid Baffle Filters
- Hybrid baffle filters utilize stainless steel baffles for an improved aesthetic and aluminum mesh for efficient filtration.
- Optional Extension Duct Cover Kit
- Extension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details.
- Airflow Control Technology(TM) (ACT(TM))
- ICON Touch(R) Controls
- LumiLight LED Lighting
- Dual-Level Lighting
- Quick-Lock Installation System
- Hybrid Baffle Filters
- Optional Extension Duct Cover Kit
Brand | Zephyr |
Manufacturer | Zephyr |
Category | Range Hood |
Sub-Category | Island |
Vent Type | Ducted |
UPC | 646328011078 |
GTIN | 00646328011078 |
Country of Origin | Taiwan |
Model Group | ZSL-C |
Model Name | Siena Pro Island |
Collection | Core Collection |
Replacement Model | ZSL-E42DS |
Blower Included | Yes |
Blower CFM w/ACT | 590, 390 |
Internal Blower 1 CFM | 1200 |
Internal Blower 1 Min. Sones | 3.5 |
Internal Blower 1 Max Sones | 9 |
Minimum CFM | 390 |
Installation Type | Island |
Installation Type | Island |
For Outdoor Use | No |
Color | Stainless Steel |
Controls Type | ICON Touch® |
Blower Speeds | 5 |
Automatic Delay-Off | Yes |
Clean Air Function | No |
Lighting Type | LED |
Lights Quantity | 2 |
Watts Per Bulb | 6 |
Lights Levels | 2 |
Grease Filter Type | Hybrid Baffle |
Compatible Mesh or Baffle Filter Part Number | 50200050 |
Duct Discharge | Vertical |
Duct Size; Horizontal; IN | N/A |
Duct Size; Vertical; IN | 10 |
Mounting Height Above Cooktop; IN | 24 - 34 |
Voltage | 120 |
Maximum Amperage | 8 |
ADA Compliant | Yes, with optional remote |
Warranty Parts / Labor | 3 / 1 |
Compatible Appliances | Z1C-01SL, MUA010A, RC-0002 |
Bluetooth Connected | No |
Wi-Fi Connected | No |
Remote Included | No |
Remote Optional | Yes |
Energy Star Certified | No |
Alexa & Google Home Compatible | No |
CEC Title 20 Compliant | Yes |
Primary Material | Stainless Steel |
Wattage | 960 |
Certification | UL |
Nominal Width; IN | 42 |
Net Width; IN | 41.875 |
Net Depth; IN | 28 |
Net Height; IN | 32.5 |
Weight; LBS | 118 |
Ceiling Height Minimum | 8 ft. |
Ceiling Height Maximum | 9 ft. |
Chimney Height in. | 32.5 |
Chimney Width in. | 15.6875 |
Chimney Depth in. | 11.9375 |
Shipping Length; IN | 32.3 |
Shipping Width; IN | 46.3 |
Shipping Height; IN | 32.4 |
Shipping Weight; LBS | 126.5 |
Shipping Method | LTL |
Freight Class | 250 |
Certification # | E127334 |
Clean Filter Alert | Yes |
Duct Type | Vertical |
Duct Type | Vertical |
