Quick Specifications
Quick Specifications
- Type : GAS RANGES
- Style : COOKTOPS (GAS)
- Width : 30"
- Height : 4"
- Depth : 20.63"
- Energy Star Rated : NO
- Wifi Connected : NO
- Downdraft Ventilation : NO
- Dual Fuel : NO
- Burner Type : Sealed
- Self Clean : NO
- Convection : NO
- Drawer Proof Mode : NO
- Continuous Grate : YES
- Sabbath Mode : NO
Documents
Documents
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
- Quality burners with cast iron caps ensure lasting durability and easier cleanup
- Solid grates make it easy to slide cookware to different burners
- Conveniently located controls offer easier and safer cooking, preventing users from reaching over hot burners to adjust the temperature
- Knobs come in a silver finish for a seamless look
- Unit is preset for natural gas but can be converted to LP with included kit
- Safety feature requires you to turn the knob to the "full-on" position before pushing down, waiting for the ignition, and adjusting to your preferred heating level
- Automatically turns gas off after 12 seconds if flame is extinguished
- Standard 3-pronged 115V cord included for the electronic ignition
- Fits counter cutout sizes that are 21.77" wide by 18.63" deep, with a trim kit that allows the cooktop to fill 30" wide openings
- Ships with a seamless stainless steel exterior trim kit that allows users to install this cooktop in 30" wide cutouts
- Center burner features a 4,400 to 11,000 BTU output with a dual ring flame for powerful but even heating
- Removable wok ring included to safely hold a wok over the flame when cooking on the center burner
- Rear right burner features a wide range output from 2,500 to 10,000 BTUs
- Front right and rear left burners offer 1,500 to 6,100 BTU output to handle most cooking needs
- Front left burner operates between 1,200 and 3,550 BTUs to best handle dishes and sauces that require low heat
- Quality design offers lasting durability in your kitchen
- Gently curved surface offers a uniquely modern look for the kitchen while also containing spills for easier cleanup
Overview | |
Nominal Height | 4.0" (10 cm) |
Height of Cabinet | 4.0" (10 cm) |
Nominal Width | 30.0" (76 cm) |
Width | 30.0" (76 cm) |
Nominal Depth | 21.0" (53 cm) |
Depth | 20.63" (52 cm) |
Cabinet | Stainless Steel |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Amps | 1.0 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 35.0 lbs. (16 kg) |
Parts & Labor Warranty | 1 Year |
UPC | 761101056715 |
Gas Cooktop | |
Ignition | Spark |
LP Convertible | Yes |
Number of Burners | 5 |
Controls | Dial |
Surface | Stainless Steel |
Grate Material | Cast Iron |
Cutout Height | 6.0" (15 cm) |
Cutout Width | 21.77" (55 cm) |
Cutout Depth | 18.63" (47 cm) |
Burner #1 BTU | 11000.0 |
Burner #2 BTU | 6100.0 |
Burner #3 BTU | 10000.0 |
Burner #4 BTU | 6100.0 |
Burner #5 BTU | 3550.0 |
Power Cord Included | Yes |
