Quick Specifications
Quick Specifications
- Type : HOODS
- Style : DUCTLESS HOOD
- Width : 29 7/8
- Height : 5 1/2
- Depth : 20
- Energy Star Rated : NO
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
Cooktop lighting
Illuminate cooking space and surrounding surface - bulbs included
Easy installation
10 minutes or less by one person
Front controls
Enjoy easy access and a subtle appearance
- Easy installation
- 10 minutes or less by one person
- Two-speed, 200-CFM venting system
- Removes smoke, grease, odors and moisture
- Front controls
- Enjoy easy access and a subtle appearance
- Cooktop lighting
- Illuminate cooking space and surrounding surface - bulbs included
- Convertible venting options
- Select recirculating or external venting
- Vertical and rear exhaust
- Exhausts from the top or rear of the hood
- Appearance (Partially enclosed bottom)
- Enjoy easy access to hood interior
- Dishwasher safe filter
- Filters grease and is dishwasher-safe
- Easy installation
- Two-speed, 200-CFM venting system
- Front controls
- Cooktop lighting
- Convertible venting options
- Vertical and rear exhaust
- Appearance (Partially enclosed bottom)
- Dishwasher safe filter
FILTER | |
App Filter - Hood Type | Under Cabinet Hoods |
App Filter - Venting Type | Convertible |
App Filter - Cabinet Width | Vent 30 in. (Standard) |
APPEARANCE | |
Blower / Light Switch Color | Black |
Material | Metal |
Color Appearance | Black |
POWER / RATINGS | |
Electrical Requirements | 120V ; 60Hz ; 2.5A |
Amp Rating at 120V | 2.5 |
WARRANTY | |
Labor Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
Parts Warranty | Limited 1-year entire appliance |
ECONOMICAL / QUIET | |
Venting Type | Convertible |
ACCESSORIES | |
Optional Accessories | JXHC1 - Power Cord Kit |
WEIGHTS & DIMENSIONS | |
Cabinet Width | 30 in |
Net Weight | 17 lb |
Overall Depth | 20 in |
Approximate Shipping Weight | 23 lb |
Overall Height | 5.5 in |
Overall Width | 29.875 in |
FEATURES | |
Cooktop Lighting | 1 Incandescent |
Fan Speed Control | 2-Speed |
Max CFM | 200 |
Ducting | Vertical or Horizontal; 7" Round |
Light Controls | On/Off |
Filter Cleaning | Dishwasher Safe |
CFM/ Sones Rating | 130/5.0 (Low Speed) 200/6.5 (High Speed) |
Exhaust Options | Recirculating Vented to Outside |
Product Type | Under Cabinet Hood |
Control Type | Rocker Switch |
Control Location | Front |
Charcoal Filter | JXCF53 - Included |
Removable Grease Filter(s) | Yes |
