Quick Specifications
Quick Specifications
- Type : HOODS
- Style : DUCTLESS HOOD
- Energy Star Rated : NO
Documents
Documents
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
- Total Integration
- The total look trend is becoming increasingly popular in kitchens now, guaranteeing a uniform, linear design with respect to the space. The Total Integration products have been designed to be seamlessly integrated into the kitchen whilst maintaining harmony with the surroundings.
- Long Life Filter
- To ensure the best performance and long-term duration of your hood, the traditional filters must be replaced every 3-6 months. To simplify the maintenance operations, Elica has designed the innovative, regenerable Long Life odour filter which lasts up to three years. Just wash it with hot water and neutral soap or in the dishwasher at 65(degree) and dry it in the oven at 100(degree) for ten minutes every two months to keeping it looking good as new. The level of efficiency is about 60%.
- Dim Light
- The light in the kitchen, as in any room, is a key design feature for improving the home living experience. Achieving the right intensity becomes fundamental in creating the desired atmosphere. Which is why Elica has designed the Dim light function which allows you to adjust the intensity of your extraction hood light with a simple control. Maximum light for the best visibility on the worktop or dimmed when relaxing.
- Tune White
- Selecting various lighting tones can be very useful, based on certain moments and household activities. A cool light is best for cooking, but a warm light creates a more relaxing mood. With the Tune White feature, it is possible to adjust the LED colors, from warm white, to cool white, matching the hood lights to those of the room, for a uniform atmosphere throughout the space.
- Perimeter Aspiration
- First developed by Elica, this technology literally turned the market 180 degrees and opened the door to hoods that could be mounted on the wall like picture frames. The technology draws air through a narrowed channel around a face plate, which increases suction, without increasing blower speed or energy consumption.
- Tune white
- Long life filter
- Dim light
- Total integration
- Super easy installation
- Remote control
- Perimeter aspiration
- Panel ready
Warranty | 3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
SHIPPING WEIGHT (kg) | 32.80 |
NET WEIGHT (kg) | 24.20 |
CARTON LENGHT (mm) | 1129.00 |
CARTON HEIGHT (mm) | 385.00 |
CARTON WIDTH (mm) | 661.90 |
VOLUMEN (M3) | 0.30 |
SHIPPING WEIGHT | 72.31 |
NET WEIGHT | 53.35 |
CARTON LENGHT | 44.45 |
CARTON HEIGHT | 15.16 |
CARTON WIDTH | 26.06 |
COUNTRY OF MANUFACTURE | MX |
QTY PACKAGE | 1.00 |
INTENDED APPROVED USE | Residential use |
Finish | Stainless Steel + panel ready |
Color | custom |
Type of Ventilation | Convertible |
HOODS FEATURES | Tune white,Long life filter,Dim light,Total integration,Super easy installation,Remote control,Perimeter aspiration,Panel ready, |
WIDTH (IN) | 40" |
WIDTH (CM) | 100.00 |
AIRFLOW (M3/H) | 1020 / 2040 |
CFM (MAX) | 600/1200 |
db (min) | 38 / 40 |
db (max) | 58 / 61 |
SONES | 2.0-8.0 / 2.3-10.2 |
EXHAUST VERSION | Convertible with Kit |
EXHAUST SIZE | Round 6" Multidirectional |
DUCT SHAPE | Round |
EXHAUST LOCATION | Multidirectional |
RECTANGULAR DUCTH HEIGHT | NA |
RECTANGULAR DUCT WIDTH | NA |
Round duct diameter | 6" |
ELECTRIC (VOLTS) | 120 V/60 Hz |
AMPERAGE | 4 A/8.53 A |
HERTZ | 60.00 |
WATTS | 578.00 |
LIGHTING | Dimmable Strip LED 2 x 14 ww 3500 KK |
BULB TYPE | Strip LED |
BULB INCLUDED | YES |
NUMBER OF LIGHTS | 2.00 |
BULB WATTS | 14.00 |
KELVINS | 3500.00 |
GREASE FILTER TYPE | Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration |
DISHWASHERSAFE FILTER | YES |
FILTER MATERIAL | Aluminum Mesh |
BLOWER TYPE | Sold separately |
CONTROL TYPE | Remote control |
SPEED CONTROL | YES |
NUMBER OF SPEEDS | 4.00 |
REMOTE CONTROL | YES |
POWER SOURCE | Junction Box |
OUTDOOR USE | NO |
SMUDGE RESISTANT | NO |
RECIRCULATION KIT NEEDED | YES |
CFM REDUCTION | Yes w/kit |
DIMENSIONS | 101 x 49 x 32 |
DIMENSIONSinches | 40"x 19 1/2" x 12 5/8" |
ADJUSTABLE HEIGHT | NO |
Minimum Overall Height - Top to Bottom | 12 1/16" |
Maximum Overall Height - Top to Bottom | 12 1/16" |
Overall Height - Top to Bottom | 12 1/16" |
Overall Width - Side to Side2 | 40" |
Overall Depth - Front to Back | 19 7/8" |
Hood Height | 12 1/16" |
Minimum Compatible Ceiling Height | NA |
Maximum Compatible Ceiling Height | 10'0" |
Minimum Height Above Cooktop (ELECTRIC) | = 24 |
Minimum Height Above Cooktop (GAS) | = 30 |
Maximum Height Above Cooktop | NA |
Chimney Width - Side to Side | NA |
Chimney Depth - Front to Back | NA |
Chimney Height - Top to Bottom | NA |
RECIRCULATION KIT NUMBER | KIT0192765 |
CHIMNEY EXTENSION NUMBER | NA |
TELESCOPIC DUCT COVER | - |
DUCT TRANSITION | - |
TRANSITION REDUCER KIT | - |
BACKDRAFT DAMPER | - |
NON RETURN VALVE | - |
UPGRADE FILTER | - |
CFM REDUCTION KIT | KIT0185099/KIT0185752 |
BACKSPLASH KIT | - |
INTERNAL BLOWER | KIT0198146/KIT0198147 |
INLINE BLOWER | KIT0154387/KIT0198148 |
EXTERNAL BLOWER | KIT0153054 |
INLINE BLOWER SHELL KIT | - |
EXTERNAL BLOWER SHELL KIT | - |
HEAT LAMPS | - |
SPACER/LINER | - |
WALL MOUNT BRACKET | - |
HIGH CEILING EXTENSION KIT | - |
REMOTE CONTROL KIT | KIT0121469 |
cUL listed | YES |
UL listed | YES |
AHAM verified | YES |
TITLE 24 | YES |
Prop65Disclosure | YES |
ENERGY STAR | NO |
WIFI CAPABLE | NO |
COMERCIAL USE APPROVED | NO |
ADA COMPLIANT | YES |
APP CAPABLE | NO |
VENTILATION DIRECTION | HORIZONTAL |
SMART COMPATIBLE | NO |
FITLER INDICATOR LIGHT | YES |
HEAT SENSOR | NO |
CHAROCAL FILTER | YES |
CERTIFICADO NOM | Activo |
