Quick Specifications
Quick Specifications
- Type : DISHWASHERS
- Style : BUILT IN DISHWASHER
- Height : 33.81"
- Depth : 21.81"
- Energy Star Rated : YES
- Wifi Connected : YES
- Sabbath Mode : NO
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
![Green mode](https://images.webfronts.com/cache/frahicfgjytc.jpg)
Green mode
The Green mode saves water and energy by lowering the temperature and extending the washing cycle. Still, the result is just as perfect as the Normal program. Let s go greener!
![Light Lock(TM)](https://images.webfronts.com/cache/frekgaalywmi.jpg)
Light Lock(TM)
Light plastic cans and bowls are easily flipped over and filled with water. The LightLock(TM) smart fixation helps them to retain their position throughout the program.
![ECO wash](https://images.webfronts.com/cache/frbvetzstpxt.jpg)
ECO wash
Use when you want to save water and energy. For normally soiled load, such as plates, serving dishes, cups, glasses and so on.
![LED interior light](https://images.webfronts.com/cache/frjxxlbjqrcd.jpg)
LED interior light
The combination of outer and inner LED-lights is designed for best intensity and durability. It gives you a good overview of the door area as well as the inside of the dishwasher.
![Turbo Combi Drying(TM) with sensor control](https://images.webfronts.com/cache/frmgvflynadj.jpg)
Turbo Combi Drying(TM) with sensor control
Turbo Combi Drying(TM) with sensor controlThis is our most advanced drying method. It is based on the same principles as Turbo Combi Drying, but the automatic door opening is regulated by a sensor that measures the temperature in your kitchen. If the kitchen is colder than normal, the door will open at a later stage. If it is warmer, the door opens earlier. This means that energy for drying is used more efficiently.
![Time program](https://images.webfronts.com/cache/frxkxycworkj.jpg)
Time program
When you need clean plates in a hurry, just tell the machine how dirty the dishes are and how much time you have. The program then adjusts washing and rinsing to match your needs.
![Brushless motor](https://images.webfronts.com/cache/frpgpfrgdwfg.jpg)
Brushless motor
A brushless motor is not only quieter and more reliable. It also consumes less energy. You want your dishwasher to work forever. So do we.
![Crystal Glass](https://images.webfronts.com/cache/frljdorinrhn.jpg)
Crystal Glass
Wash fragile items made of crystal/glass, such as crystal glass from Orrefors, using the gentle dishwashing program Crystal glass.
![Top cutlery tray](https://images.webfronts.com/cache/frmjahteqqff.jpg)
Top cutlery tray
The top tray for cutlery and kitchen utensils is easy to remove for easy unloading. With a width of 12-3/4" the centred tray leaves plenty of room for tall wine glasses in the upper rack on each side of the tray. And with the Instant Lift(TM) you have the freedom to adjust the upper rack to be 1-1/2" or 2-1/4".
![Status Light(TM)](https://images.webfronts.com/cache/frrawypbyyvw.jpg)
Status Light(TM)
ASKO s new generation dishwashers have Status Light(TM) -a small light placed in the bottom right corner to let you know the actual status of the program.
![Aqua Safe(TM) system](https://images.webfronts.com/cache/frhkwjcmndih.jpg)
Aqua Safe(TM) system
Do you hesitate to leave the dishwasher on while you are not at home? Aqua Safe(TM) system is an advanced safety system which ensures a leak-safe dishwasher day and night.
![Vase/bottle holder](https://images.webfronts.com/cache/frdquqocipzk.jpg)
Vase/bottle holder
Our special holder for tall, narrow objects like baby bottles, vases and bottles is combined with a special power zone that makes sure that the cleaning result is perfect.
![UV Cleanse](https://images.webfronts.com/cache/frqutbyhvakz.jpg)
UV Cleanse
UV Cleanse modeWhen it comes to getting dishes and cutlery really clean, there are four important ingredients: temperature, chemistry, mechanical action and time. When developing our new DW60 series of dishwashers, we wanted to take cleanliness and hygiene to the highest level. So, we added a fifth and unexpected ingredient - light. UV light, to be exact. For our bodies, moderate exposure to UV light is a good source of vitamin D. It improves our mood and boosts our energy. But what about our dishes? Well, UV light is also proven to kill bacteria. This is why we decided to build our latest dishwashing innovation around it, enabling up to 99,99999 % bacterial elimination.
![Speed mode](https://images.webfronts.com/cache/frroysueimum.jpg)
Speed mode
When you need to get things cleaned in a hurry, the Speed mode is useful. It saves up to 50% of the normal time, by using more water and increased heating.
![Self Cleaning](https://images.webfronts.com/cache/fruddevvdyex.jpg)
Self Cleaning
ASKO s dishwashers have a Self-cleaning program to ensure that all vital parts are thoroughly cleaned. Use a recommended cleaning agent and the program on a regular basis for best result.
- Turbo Combi Drying(TM) ensures dry dishes with fan assisted evacuation of moisture in combination with Auto Door Opening
- No
Noise level (max) | 39 dB(A) |
Number of place settings | 18 pcs |
Number of racks | 4 |
Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lock™ for fastening lightweight items |
Size | XXL |
Automatic dosing system | Panel Ready |
Installation | Panel ready |
Series | Style |
Construction and performance | |
8 Steel™ - Vital parts of the dishwasher made in stainless steel | Yes |
No need to rinse the dishes thanks to Super Cleaning System™ | Yes |
Automatic water-softener for better washing performance | Yes |
Number of spray arms | 3 pcs |
Number of spray zones | 10 |
Cleaning systems | Twin Tubes™ - separate spray zone for the middle basket Cutlery Spray™ - Extra dishwashing power for the cutlery basket No need to rinse the dishes thanks to Super Cleaning System™ Aqua Level™ Sensor Sensi Clean™ Sensor - measures dirtiness level Stainless steel spray arms Adjustable power zones that can be set for cleaning Pots & Pans or Bottles & Vases. Can also be turned off. The water pressure is adapted depending on program, type of dishes and dirtiness level. |
Use and flexibility | |
Number of place settings | 18 pcs |
Number of racks | 4 |
Top tray | Easy height adjustment With telescopic rails Handle Removable Guide rails with ball bearings |
Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lock™ for fastening lightweight items |
Upper basket system | Easy height adjustable with lever |
Upper basket | Dividable pin rows Wine glass fixings in TPE Sliding tines for easy adaptation to stone ware etc. Perfect ergonomy with easy sliding telescopic rails Light Lock™ for fastening lightweight items China Guard - Protects fragile load from the rotating spray arm Extra wide knife stand Two foldable glass supports Divisble/foldable wine shelves to left Foldable wine shelves to right Handle with ASKO logo Small distance between the basket threads - makes loading easy and prevents small items to fall through |
Middle basket | Removable rack for large utensils Removable rack for bowls, cups and glasses Handle Middle basket connection fitted with non-return valve Perfect ergonomy with easy sliding telescopic rails |
Lower rack type | Exclusive |
Lower rack | Sliding tines for easy adaptation to stone ware etc. Cutlery basket Vase/bottle holder for cleaning vases/baby bottles Foldable/divisible front pin row Foldable/divisible rear pin row Handle with ASKO logo Small distance between the basket threads - makes loading easy and prevents small items to fall through. |
Automatic dosing system | Panel Ready |
Interior light | Yes, 4 LED lights |
Interaction and control | |
Possible to control via Wi-Fi | Yes, integrated |
Type of display | Graphic TFT display |
Status Light™ - Visual indication of dishwashing progress | Yes |
Remaining time indication | Yes |
Wash end indication | Displayed with sound and light |
Language settings | Chinese simpified Chinese traditional Swedish Slovenian Slovak Russian Portuguese Polish Norwegian Dutch Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English German Danish Czech Ukrainian |
Functions, programs and modes | |
Programs | Anti odour Sanitize Light wash Self cleaning Quick Pro wash Crystal glass Lower half Upper half Rinse and hold programme Plastic wash Time program ECO wash Standard Auto wash Intensive program |
Delayed start | Possible to delay up to 24 hours |
Options and modes | Heat Boost Mode Push to open - Handle-free door opening Sensor controlled door opening - Optimizes the drying process according to the room temperature ExtraHygiene with UV Technology Night mode - Lower noise level. The program time is extended. Speed mode - The program time is shortened. More energy is used. Green mode - Less energy and water is used. The program time is extended Time set Super Rinse™ - Two extra rinses Enable/disable automatic door opening |
Design and integration | |
From the front adjustable door spring | Yes |
From front adjustable rear foot | Yes |
Installation | Velcro strips for easy mounting and adjustment of the separate custom door Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated installation Trim kit Steam protection strip |
Sliding door | No |
Possible to install elevated | Yes |
Custom door size | Custom door size 700-800 |
Min. niche width | 24 '' |
Min. niche height | 33 7/8 '' |
Depth (incl. wall spacing) | 21 7/8 '' |
Height setting | 2 1/16 '' |
Adjustable kick plate | 30-94/0 |
Safety and maintenance | |
Aqua Safe™ | Anti Block™ - Self cleaning drain pump Light and sound alarm Maximum time for water intake Extra durable PEX inlet hose Stand-by water protecion - Leakage detection when machine is off Aqua Level™ Sensor - Ensures an optimized water level Aqua Detect™ - Instant recognition of any leakage in the motor compartment Detection of water leakage on the bottom plate Waterproof bottom plate Extra durable stainless steel container Sealing points outside container |
Aqua Safe™ system | Yes |
Child safety | Kid Safe™ - Lockable controls |
Indication of low level of rinse-aid | Notification in display |
Salt refill indicator | Notification in display |
Technical data | |
Water connection | Hot&cold water |
Adapter for water connection | No |
Max. temperature of inflow water | 140 °F |
Noise level (max) | 39 dB(A) |
Reference programme | 1 |
Duration of standard programme | 125 min |
Estimated yearly energy consumption | 230 kWh |
Energy consumption - normal program | 1 kWh |
Estimated annual water consumption | 687.4 gal |
Water consumption | 3.2 gal |
Power consumption in standby mode | 0.5 W |
Plug type | USA |
Connected load | 1300 W |
Voltage (V) | 120 V |
Number of phases | 1 |
Fuse | 15 A |
Frequency | 60 Hz |
Required inlet water pressure psi | 0,03-1 |
Net weight | 106.9 lb |
Dimensions | |
Width | 23 15/16 '' |
Height | 33 13/16 '' |
Depth | 21 13/16 '' |
Maximum product height | 35 7/8 '' |
Length of electrical cord | 71 7/16 '' |
Depth with door open | 48 7/16 '' |
Length inlet hose | 64 3/16 '' |
Length outlet hose | 90 9/16 '' |
Logistic information | |
Packaging width | 25 3/16 '' |
Packaging height | 36 5/8 '' |
Packaging depth | 26 3/4 '' |
Gross weight | 114.2 lb |
Product code | 740094 |
EAN code | 3838782628535 |
Noise level (max) | 39 dB(A) |
Number of place settings | 18 pcs |
Number of racks | 4 |
Upper rack type | Exclusive, all tines are foldable, divisble/foldable wine shelves, Light Lock™ for fastening lightweight items |
Size | XXL |
Automatic dosing system | Panel Ready |
Installation | Panel ready |
Series | Style |
